# CS 2120: Class #15¶

## Some things¶

Let’s draw a Koch Snowflake on the board.

Let’s write a program that does this:

Let the user pick some complex parameter c For every complex number (r,i) in a bounded plane: z = c while z is not *really big*: z = z*z + c if z has convereged, this point is 'in' this point is 'out'

(Mathematically, of course,

*really big*isn’t enough, we’re looking for values that diverge to infinity... but Python doesn’t do infinity so well, so here we are)A full Python version is here

Let’s plot that set (black dot for elements in the set, coloured dot otherwise – colour indicating how fast the value goes to infinity), and then zoom in on it: Mandlebrot zoom

Activity

What do all of these things (The Escher Drawing, the Bach Fugue, the fractals) have in common?

Activity

What does the following Python code do. Try to figure it out *without* running
it. What’s new about how it works?:

```
def my_func(n):
if n < 1 :
return 0
else:
return n + my_func(n-1)
```

- We have discovered
*recursion*. - Hold onto your hats folks!

- We have discovered
Let’s go back and trace the execution of our function on the board (pencil & paper debug) for a test case.

Activity

Fill out the instructor evaluations!

Warning

Pay really close attention here. The intuition we’re going to gain from walking through this simple example is critical.

## Recursion¶

If a function calls

*itself*, it is said to be a*recursive function*.You’ve seen recursion before in your math classes (e.g., recurrence relations)

- Why would you want to have a function call itself??
- Well, maybe you want to repeat a section of code multiple times...
- ... like a loop!

Anywhere you can use a loop, you could also use recursion. The underlying effect is the same: repeating a chunk of code multiple times.

The

*semantics*of how that happens are a bit different.Some languages (e.g., Scheme)

*forbid*loops and allow only recursion.Some languages (e.g., Fortran 77)

*forbid*recursion and allow only loops.Most allow both because some problems are easier to solve with loops... and some are easier to solve with recursion.

There is

*nothing*that can be done with recursion that can’t be done with loops (and vice-versa). This is a mathematically provable*theorem*.However, some things are

*a lot easier*with one or the other.

## Thinking Recursively¶

To really “think recursively” requires us to rewire ourselves a bit.

Recursion is, without question, the most difficult CS1 topic for most students.

If you’re frustrated, stop me and ask questions.

Recursion is so incredibly powerful in some instances, that you simply can’t be a good programmer without mastering it. But that takes time. Expect frustration.

## The dark side of recursion¶

Activity

I’ve modified the function we wrote above to add up only every *other* number.

Try running this new version with the call `my_func(8)`

.

Now try: `my_func(7)`

. What happened? Can you figure out how to fix it? (assuming you didn’t want this to happen):

```
def my_func(n):
if n == 0:
return 0
else:
return n + my_func(n-2)
```

## Writing a simple recursive function¶

I’m going to give you some rules for writing recursive functions.

By following these rules, we can avoid the catastrophe we just had.

(When you get sophisticated enough, you’ll find situations in which it’s OK to stretch/violate these rules.)

- Every recursive function needs two things:
- A
**base case**that*terminates*the recursion. - A
**recursive step**that calls the function again, but with a modified (probably smaller) parameter.

- A

Activity

Identify the **base case** and **recursive step**
in this function:

```
def my_func(n):
if n < 1 :
return 0
else:
return n + my_func(n-1)
```

Now it’s your turn:

Activity

Using “the rules”, write a function `fact(n)`

which computes the factorial
of `n`

*using recursion* (no loops allowed!!). Remember that factorial
is defined as n! = n * (n-1) * (n-2) * ... * 2 * 1. So, for example,
5! = 5 * 4 * 3 * 2 * 1 = 120 .

## Recursive Data Structures¶

Recursive algorithms often work best with “recursive data structures”.

- Recursive data structures break down similarly to our approach to recursive algorithms:
**base case**: a single piece of data (e.g., an integer)**recursive case**:*everything else*in the data structure

Activity

So far, we’ve been thinking of lists as collections of values. Try to come up
with a *recursive* formulation for a list.

- Got it? Good.

Activity

Write a function `sum_list(l)`

that will return the sum of adding up
all of the elements of `l`

. You *may not* use loops! Assume that `l`

is a list of integers.

- We can think of lists as recursive, or non-recursive, data structures, depending on what we’re trying to do with them.
- This is true for
*any*data structure, though some are much more naturally thought of in one way or the other.

## Quicksort¶

You give me a list called

`inlist`

If the list has only one element, just return the list without doing anything

I pick an element from the list, which I’ll call the

`pivot`

- I
*partition*the list by shuffling the elements around so that: - all elements
*less than*`pivot`

are to the left of`pivot`

- all elements
*greater than*`pivot`

are to the right of it

- all elements

- I
- I
*recursively call*quicksort on two lists: - The list of stuff to the
*left*of`pivot`

- The list of stuff to the
*right*of`pivot`

- The list of stuff to the

- I

Activity

Do a quicksort, with pencil and paper, on the list `[3,7,15,9,4,11,1,5,2]`

.

Record the value of your list at each step.

You can see why we waited to study Quicksort.

- The idea of recursion is
*central*to the description - You can, of course,
*implement*quicksort without using recursion, but it’s a bit uglier.

- You can, of course,

- The idea of recursion is
Thinking recursively, it’s a very clean divide-and-conquer strategy.

Let’s try it:

def partition(list, l, e, g): while list != []: head = list.pop(0) if head < e[0]: l = [head] + l elif head > e[0]: g = [head] + g else: e = [head] + e return (l, e, g) def quicksort(list): from random import choice print list if list == []: return [] else: pivot = list[0] less, equal, greater = partition(list[1:],[],[pivot],[]) return quicksort(less) + equal + quicksort(greater)

Activity

Modify the `quicksort()`

function above so that it prints out the value of `list`

every time it is called.

Try sorting a few lists and following the output.

Activity

What is the **base case** in `quicksort()`

?

What is the **recursive case**?

There are *no loops*... so how do I figure out how long it takes to sort a list with `n`

elements? In the worst case? In the average case? Do you think this is a good sort? How does it compare to selection or insertion sort?

A definite improvement, but still not great in the worst case. Can we do better?

## Mergesort¶

You give me a list,

`inlist`

with`n`

elementsI divide

`inlist`

into`n`

sublists, each having 1 element.The sublists are now already sorted! (Any list with only one element is automatically sorted)

- I now begin
*merging*sublists, to produce bigger (but still sorted) sublists: - I compare the first element in one sublist to the first in the other
- Whichever is smaller goes into the merged list
- I now compare the
*second*element in that list to the first element in the other list - ... and so on...

- I now begin
I keep going until there is nothing left to merge (there’s only

*one*big, sorted, list)

Activity

Do a mergesort, with pencil and paper, on the list `[3,7,15,9,4,11,1,5,2]`

.

Record the value of your list at each step.

Let’s start by implementing a

`merge`

operation in Python:def merge(left, right): merged = [] l=0 r=0 while l < len(left) and r < len(right): if left[l] <= right[r]: merged.append(left[l]) l = l + 1 else: merged.append(right[r]) r = r + 1 if l < len(left): merged.extend(left[l:]) else: merged.extend(right[r:]) return merged

Activity

Try merging some lists with

`merge`

.Remember:

`merge`

expects that the lists it is merging arealready sorted!! If the lists to merge weren’t already sorted, what would have to change about`merge`

?

Okay, now the real deal:

def mergesort(list): if len(list) <= 1: return list else: midpoint = int( len(list) / 2 ) left = mergesort(list[:midpoint]) right = mergesort(list[midpoint:]) return merge(left,right)

Wow, that was short! WTF is going on in there?

Activity

Modify the `mergesort()`

function above so that it prints out the value of `list`

every time it is called.

Try sorting a few lists and following the output.

Activity

What is the **base case** in `mergesort()`

? What is the **recursive case**? How many recursive calls will I make to `mergesort()`

for a list of size `n`

on average? In the worst case?

## Recursion¶

This has been a tiny taste of recursion.

If you take more CS courses, you’ll see more recursive algorithms and you’ll develop an intuition for when it’s advantageous to use recursion.

- The official “learning goals” for this class though, are much more modest:
- Exposure to recursion
- Ability to define recursion
- Ability to recognize recursion in a Python function

If you actually

*understand*recursion with no effort, then you are*way*ahead of the curve and should consider a CS major.- If you don’t totally “get it”... you’re normal. Here’s the secret to “getting it”:
- Practice.

## The even darker side of recursion¶

- Let’s start with a warmup:

Activity

Is the following statement true or false: “This statement is False.”?

Activity

What happens when Pinocchio says: “My nose is going to grow now.”?

- And then get down to business...

Activity++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

Can you write a Python program that will look at a Python function and determine if the function might go into an infinite loop?

Let’s assume the answer to this activity is “yes” and see where that gets us.

Based on our assumption, I can write a function called

`youre_screwed(func)`

that takes some arbitrary Python function`func()`

as its input.- If
`func()`

goes into an infinite loop,`youre_screwed()`

prints “Infinite loop in`func()`

” and`returns`

- If
`func()`

doesn’t go into an infinite loop, this (perverse) function,`youre_screwed()`

,*does*go into an infinite loop (I told you it was perverse).

- If
So... what happens if I execute:

>>> youre_screwed(youre_screwed)

???
